Cruiser
- Displacement1103 cc
- Maximum power133.8 kW
- Maximum torque120 Nm
- Weight220 kg
Specifications
Other declared specifications19 items
- Type
- Ducati Desmosedici stradale, V4 - 90°, 4 valves per cylinder, counter-rotating crankshaft, twin pulse firing order, semi dry sump, liquid cooled
- Fuel Injection
- Electronic fuel injection system, Øeq 50mm equivalent elliptical throttle bodies with Ride-by-Wire system
- Exhaust
- Exhaust muffler in titanium
- Primary drive
- Straight cut gears; Ratio 1,80:1
- Ratio
- 1=40/13, 2=36/16, 3=36/20, 4=31/21, 5=29/23 , 6=27/25
- Front Wheel
- Forged, 3.5" x 17"
- Rear Wheel
- Forged, 8.0" x 17"
- Wheel Travel (Front/Rear)
- 4.7 in / 5.7 in (120 mm / 145 mm)
- Instrumentation
- 5'' TFT color display
- Number of Seats
- 2
- Safety Equipment
- Riding Modes, Power Modes, Ducati Traction Control (DTC), Ducati Wheelie Control (DWC), Bosch Cornering ABS
- Standard Equipment
- Ducati Quick Shift (DQS) up/down 2.0, Öhlins suspension, Lithium-ion battery, Forged aluminum wheels, Single seat configuration, Cruise control, Ducati Power Launch (DPL), Ducati Multimedia System (DMS), TFT color display, Hands-Free, Full LED lighting system, Full LED headlight, Self cancelling turn indicators, Lap Timer, Turn-by-Turn navigation system, USB port, Backlit handlebar switches, Front mudguard in carbon fiber , Rear mudguard in carbon fiber , Fuel tank side covers in carbon fiber, Flyscreen in carbon fiber, Clutch cover in carbon fiber, Tail in carbon fiber, Air intake side covers in carbon fiber
- Provided Equipment
- Passenger seat
- Ready for
- Anti-Theft, Tire Pressure Monitoring System (TPMS), Heated grips
- Warranty
- 24 months, unlimited mileage
- Annual Service
- 12 months
- Oil Service
- 9,000 mi (15,000 km) / 24 months
- Valve Clearance Check
- 18,000 mi (30,000 km)
- Notes
- Bike specifications and equipment may vary from market to market. Please refer to your local dealer for further information
Engine5 items
- Engine displacement
- 1103ccSource wording: 1,103 cc (67.3 cu in)
- Bore × stroke
- 3.2 in / 2.1 in ( 81 mm / 53.5 mm)
- Compression ratio
- 14.0:1
- Maximum power
- 133.8kWSource wording: 182 hp (133.8 kW) @ 11,750 rpm
- Maximum torque
- 120NmSource wording: 89 lb-ft (120 Nm, 12.2 kgm) @ 9,500 rpm
Fuel and transmission4 items
- Transmission
- 6 gears with Ducati Quick Shift up/down 2.0
- Final drive
- Chain, front sprocket z15, rear sprocket z43
- clutch
- Multiplate dry clutch with slipper action on over-run
- Fuel tank capacity
- 20LSource wording: 5.3 US gal (20 l)
Chassis, brakes and suspension9 items
- Frame
- Aluminum monocoque frame
- Front suspension
- Ø 48 mm fully adjustable Öhlins fork
- Front tyre
- Pirelli Diablo Rosso IV, 120/70 ZR17
- Rear suspension
- Fully adjustable Öhlins shock absorber, aluminum single-sided swingarm
- Rear tyre
- Pirelli Diablo Rosso IV, 240/45 ZR17
- Front brake
- 2 x Ø 330 mm semi-floating discs, radially mounted Brembo Stylema monobloc 4-piston calipers, radial master cylinder PR16/19, Cornering ABS
- Rear brake
- Ø 265 mm disc, Brembo 2-piston floating caliper, Cornering ABS
- Steering angle
- 26°
- Trail
- 112mmSource wording: 4.4 in (112 mm)
Dimensions and weight3 items
- Weight without fuel
- 220kgSource wording: 485 lb (220 kg)
- Seat height
- 790mmSource wording: 31.1 in (790 mm) 30.3 in (770 mm) with low seat accessory 31.9 in (810 mm) with high seat accessory
- Wheelbase
- 1602mmSource wording: 63.1 in (1,602 mm)
Sources
Specifications can vary by model year, country and variant.
