Classic
ClassicGlobal version
Ducati Formula 73Ducati Formula 73
Classic · 803 cc
Manufacturer suggested retail price19,995 USD
- Displacement803 cc
- Maximum power53.7 kW
- Maximum torque65.2 Nm
- Weight183 kg
Specifications
Other declared specifications18 items
- Type
- L-Twin, Desmodromic distribution, 2 valves per cylinder, air cooled
- Fuel Injection
- Electronic fuel injection, 50 mm throttle body with Ride-by-Wire system
- Exhaust
- Stainless steel muffler with catalytic converter, lambda probes, aluminium tail pipes
- Primary drive
- 1=32/13 2=30/18 3=28/21 4=26/23 5=22/22 6=24/26
- Ratio
- Straight cut gears, Ratio 1.85:1
- Front Wheel
- Spoked aluminium wheel 3.00″ x 17″
- Rear Wheel
- Spoked aluminium wheel 5.50″ x 17″
- Wheel Travel (Front/Rear)
- 5.9 in / 5.9 in (150 mm / 150 mm)
- Instrumentation
- 4.3″ TFT colour display
- Number of Seats
- 1
- Safety Equipment
- Riding Modes, Power Modes, Ducati Traction Control (DTC), Bosch Cornering ABS
- Standard Equipment
- Ducati Quick Shift (DQS) up/down, TFT colour display, Full LED lighting system, Self cancelling turn indicators, USB port
- Ready for
- Anti-Theft, Ducati Multimedia System (DMS), Heated grips, Turn-by-Turn navigation system
- Warranty
- 24 months, unlimited mileage
- Annual Service
- 12 months
- Oil Service
- 7,500 mi (12,000 km) / 24 months
- Valve Clearance Check
- 7,500 mi (12,000 km)
- Notes
- Bike specifications and equipment may vary from market to market. Please refer to your local dealer for further information
Engine5 items
- Engine displacement
- 803ccSource wording: 49 cu in (803 cc)
- Bore × stroke
- 3.5 in x 2.6 in ( 88 mm x 66 mm)
- Compression ratio
- 11.0:1
- Maximum power
- 53.7kWSource wording: 73 hp (53.7 kW) @ 8,250 rpm
- Maximum torque
- 65.2NmSource wording: 48 lb ft (65.2 Nm, 6.6 kgm) @ 7,000 rpm
Fuel and transmission4 items
- Transmission
- 6 speed
- Final drive
- Chain, front spocket 15, rear sprocket 46
- clutch
- Hydraulically controlled slipper and self-servo wet multiplate clutch
- Fuel tank capacity
- 14.5LSource wording: 3.8 US gal (14.5 l)
Chassis, brakes and suspension9 items
- Frame
- Tubular steel Trellis frame
- Front suspension
- Upside down Kayaba 41 mm fork
- Front tyre
- Pirelli Diablo Rosso IV - 120/70 R17
- Rear suspension
- Kayaba rear shock, pre-load adjustable
- Rear tyre
- Pirelli Diablo Rosso IV - 180/55 R17
- Front brake
- Ø330 mm disc, radial 4-piston calliper with Bosch Cornering ABS
- Rear brake
- Ø245 mm disc, 1-piston floating calliper with Bosch Cornering ABS
- Steering angle
- 22°
- Trail
- 92mmSource wording: 3.6 in (92 mm)
Dimensions and weight3 items
- Weight without fuel
- 183kgSource wording: 403 lb (183 kg)
- Seat height
- 808mmSource wording: 808 mm (31.8 in)
- Wheelbase
- 1434mmSource wording: 56.5 in (1,434 mm)
Sources
Specifications can vary by model year, country and variant.
