Trail and enduro
Trail and enduroGlobal version
Triumph TF 250-CTriumph TF 250-C
Trail and enduro · 249.95 cc
PriceNot recorded
- Displacement249.95 cc
- Maximum power34.8 kW
- Maximum torque28.3 Nm
- Weight109.91 kg
Specifications
Engine8 items
- Engine configuration
- Single Cylinder 4-Stroke DOHC
- Engine displacement
- 249.95cc
- Cylinder bore
- 78mm
- Piston stroke
- 52.3mmSource wording: 2.06 in (52.3 mm) mm
- Compression ratio
- 14.4
- Maximum power
- 34.8kWSource wording: 46.67 HP (47.3 PS) / (34.8 kW) @ 13,250rpm
- Maximum torque
- 28.3NmSource wording: 20.9 lb-ft (28.3 Nm) @ 9,000rpm
- Fuel system
- Dellorto throttle body, Athena EMS
Other declared specifications6 items
- Exhaust
- Single silencer
- Swingarm
- Aluminum Fabrication
- Front wheel
- Spoked, tubeless, 21 x 1.6 in
- Rear wheel
- Spoked, tubeless, 18 x 1.85 in
- Instruments
- Hour meter, multi-function switch cubes
- Wheel base
- 58.74 in (1492 mm)
Fuel and transmission4 items
- Final drive
- Chain, 13T/48T
- clutch
- Wet, multi-plate, spring (Belleville)
- Transmission
- 5-Speed
- Fuel tank capacity (as stated in source)
- 2.2 gal
Chassis, brakes and suspension9 items
- Frame
- Aluminum, Spine & Double Cradle
- Front tyre
- 80/100-21
- Rear tyre
- 110/100-18
- Front suspension
- KYB 1.89” (48mm) Coil Spring Fork, Compression/Rebound Adjustment, 12.2” (310mm) Travel
- Rear suspension
- KYB Coil, Compression Adjustment (H and L Speed), Rebound Adjustment, 12.0” (305mm) Travel
- Front brake
- Brembo Twin .94” (24mm) Piston, 10.2” (260mm) Disc
- Rear brake
- Brembo Single 26mm Piston Caliper, 220mm Disc
- Steering angle
- 27.4 °
- Trail
- 116mmSource wording: 4.57 in (116 mm)
Dimensions and weight4 items
- Width
- 836mmSource wording: 32.91 in (836 mm)
- Height
- 1270mmSource wording: 50 in (1270 mm)
- Seat height
- 960mmSource wording: 37.8 in (960 mm)
- Ready-to-ride weight
- 109.91kgSource wording: 242.3 lb
Sources
Specifications can vary by model year, country and variant.
