Motocross
1 / 3- Displacement85 cc
- Seat height885 mm
- Fuel tank5 L
Specifications
Engine8 items
- Engine configuration
- Liquid-cooled, Single cylinder, Reed valve with YPVS, 2-stroke
- Engine displacement
- 85ccSource wording: 85cc
- Bore × stroke
- 47,5 x 47,8 mm
- Compression ratio
- 8,2 - 9,6 : 1
- Lubrication
- Premix
- Ignition
- CDI
- Starting
- Kick
- Cooling system
- Liquid-cooledSource wording: Liquid-cooled, Single cylinder, Reed valve with YPVS, 2-stroke
Fuel and transmission4 items
- clutch
- Wet, Multiple Disc
- Transmission
- Constant Mesh, 6-speed
- Final drive
- Chain
- Fuel tank capacity
- 5LSource wording: 5,0 L
Other declared specifications10 items
- Carburettor
- Keihin PWK28/1
- Caster Angle
- 26° 00
- Front suspension system
- Telescopic fork
- Rear suspension system
- Swingarm, (Link type suspension)
- Front travel
- 275 mm
- Rear Travel
- 287 mm
- Wheel base
- 1.285 mm
- Minimum ground clearance
- 360 mm
- Wet weight (including full oil and fuel tank)
- 75 kg
- Oil tank capacity
- 0,5 L
Chassis, brakes and suspension6 items
- Frame
- Semi double cradle
- Trail
- 99mm
- Front brake
- Hydraulic Single Disc, Ø220 mm
- Rear brake
- Hydraulic Single Disc, Ø190 mm
- Front tyre
- 70/100-19 42M Tube type
- Rear tyre
- 90/100-16 52M Tube type
Dimensions and weight4 items
- Length
- 1.9mmSource wording: 1.895 mm
- Width
- 760mm
- Height
- 1.18mmSource wording: 1.175 mm
- Seat height
- 885mm
Sources
Specifications can vary by model year, country and variant.
